12 Head Manual Belt Weigher For Weighing Fish, Noodle, Shrimp
The 12-head manual belt weigher adopts a unique belt-type open weighing tray design structure, which effectively responds to sticky, bulky shapes and other poorly flowing materials, such as fish, noodles, shrimp, and other aquatic products. Meat, medicinal materials, and other materials. Manual feeding, so the double-row layout is adopted, which is easy for flexible operation by workshop personnel.
Features
1. Using high-precision, high-standard special load cells.
2. The modular circuit board realizes intelligent multi-sampling stable mode, and the weighing is more accurate.
3. Intelligent fault alarm, convenient maintenance.
4. Concentrated discharge mode to ensure the relative concentration of materials and improve the running speed of the machine.
Intelligently customize the number of weighing trays to achieve double standards of weighing and c
Mechanical character
1. Double row linear layout, easy to operate by workshop staff.
2. Belt-type open weighing tray design structure can effectively solve the feeding of sticky or bulky materials with poor fluidity.
3. Visualize LED signal light, clear the feeding direction and feeding area, and effectively identify the current status of the corresponding tray.
4. Easily detachable conveyor belt, easy to clean.
5. HMI interface to facilitate self-learning and exchange of information.
Technical specification
| Model | JW-A12 | JW-A14 |
| Identify Code | A12-2-5 | A14-2-5 |
| Weighing Range | 10-6000g | 10-6000g |
| Accuracy | X(0.5) | X(0.5) |
| Max Speed | 30P/M | 25P/M |
| Protection Class | IP65 |
| Weighing Belt Dimension | 300(L)x180(W) |
| Control Panel | 10.1” Touch Screen |
| Driving System | Step Motor |
| Power Requirement | 220V/800W/50/60Hz/3.6A |
| Packing Dimension(mm) | 2200(L)x1200(W)x1160(H) | 2560(L)x1200(W)x1160(H) |
| Gross Weight | 370kg | 450kg |
Application
It's suitable for weighing large block, strip, and stem materials with poor fluidity, such as fish, noodles, shrimp, and other aquatic products, meat products, medicinal materials, and other materials.
Domestic and international service
A.2 years warranty:
All our customers who buy Kenwei machines will enjoy a two-year warranty. Only high-quality can ensure the stable operation of combination weigher with the extremely low failure rate. From recent statistics, the failure rate of Kenwei machines is less than 0.5% within1year, and failure rate within 2 years is less than 1%.
B.Organization:
Kenwei service department is including test group, planning group, door-to-door service groups, etc, mainly to provide commission for specific materials and make commission regularity indicators so that to find out the suitable material for the machine; Also, they are responsible for customer training and online operating skills, including installation manual and maintenance manual provided. Above are customer accepted initiatives.
C.High efficiency: Kenwei has a high efficient service team. When customers encounter problems,98.5% of the problems get a reply within the same day, and spare part is sent within 3 days if needed.
D.Record: Each Kenwei machine has a product code and components number, which has a corresponding configuration, photos, and more machine detailed records, so that we can help customers solve problems quickly when problem comes. Also, the technical department makes a modular design for a unit that makes component replacement more simple and fewer troubles.
